Glass Beveling Polishing Processing Machine for Mirror/Buliding

High Precision Beveling Edging Processing Machine For Glass

Glass Beveling Polishing Processing Machine for Mirror/Buliding





Technical Specifications:
Processing speed0.8~4.1m/min
Min.glass size120×120mm
Glass Thickness3~19mm
Bevel width40mm
Bevel angle(θ)3°~30°
Size of whole machine(mm)7800X1400X2500mm
Weight(kg)3800
Power(kw)22.83
spindles9pcs



Glass Beveling Polishing Processing Machine for Mirror/Buliding

Wheel disposalWheelfunction

No.1Diamond wheelRough beveling
No.2Diamond wheelRough beveling
No.3Diamond wheelBottom grinding
(pencil edge)
No.4Resin wheelFine beveling
No.5Resin wheelFine beveling
No.6Resin wheelFine beveling
No.7Wool wheelBevel polishing
No.8Wool wheelBevel polishing
No.9Wool wheelBevel polishing



General Information:
1. XM351 is designed for grinding and polishing a bevel edge, with bottom edge of glass with different size and thickness.
2. Rough grinding, fine grinding, polishing of bevel and grinding of bottom edge can be completed in one time.
3. The processing speed is adjustable with stepless motor.
4. Input and output conveyor adopt timing belt which can improve the transmission precision.
5. It is easy to operate and has good performance.
6. The wheels and motor adopt direct transmission;
7.The machine with lubricating system
8. This machine had two options, one is digital display. There are four meters; they will display processing speed, glass thickness, glass bevel angle, surplus thickness. And the other one is Schneider PLC Control with touch screen.
